TMR-06 Spring-Cable TM Probe (RJ11)
Coiled cable stretching to 1.8 m with an RJ11 plug — reach the key, not the desk.
A handheld probe on a coiled cord that extends to 1.8 metres (other lengths are confirmed in the quote) and plugs in with a standard RJ11 connector — no soldering needed. The ABS capsule is designed to isolate ground from the outer case. Designed for enrolment desks, cashier stations, service counters and any workflow where the reader is brought to the key rather than the other way round.
Ordering information
| MOQ | Confirmed by model and order when quoting |
|---|---|
| Preparation time | Availability and lead time are confirmed by model and order when quoting |
| Packing | Confirm pack quantity, protection and labelling for the selected model. |
| Samples | Sample quantity, fees and shipping are confirmed for the selected model. |
| Payment | Agree payment terms and the payee in the quotation and invoice. |
| Shipping | Confirm the shipping method, cost and timing for your destination and order. |
| Customization | State ROM, colour, marking and packing needs; feasibility and cost require confirmation. |
Key features
- Coiled cord extends to 1.8 m and recoils out of the way — built for counter and desk workflows.
- Standard RJ11 plug: no soldering, swap the probe in seconds.
- ABS capsule isolates ground from the outer case; chrome-plated copper contacts.
- Custom coil length can be requested; feasibility, MOQ and cost are confirmed in the quote.
Specifications
| Chip / compatibility | For DS1990A / TM1990A projects; verify the supplied key and reader versions with the target controller |
|---|---|
| Package | Chrome-plated copper contacts, ABS capsule (GND isolated) |
| Mounting | Coiled cable, 1.8 m extended (other lengths confirmed in the quote), RJ11 plug |
| Protocol | 1-Wire® |
Product dimensions
Typical applications
Frequently asked questions
What is a coiled-cable TM probe for?
For workflows where the reader is brought to the key: enrolment desks, cashier stations, service counters. The coiled cord extends to 1.8 metres and recoils out of the way.
How does it connect to the reader electronics?
Through a standard RJ11 plug — no soldering, quick to swap. Cable length and other customization options: feasibility, MOQ and cost are confirmed in the quote.
Is the ground isolated like the TMR-04?
Yes, by design — the chrome-plated copper contacts sit in an ABS capsule intended to isolate ground from the outer case, so handling it during the day should stay electrically clean. Check on your own system.
