Magnetic Dallas Key (with holder)
DS1990A key pre-assembled into a magnetic-ring key fob.
The "touch and hold" format: the key is fitted with a magnetic ring so it seats and stays on the reader contact. Supplied assembled as a key-plus-holder set; housing colour and other options are confirmed in the quote.
Ordering information
| MOQ | Confirmed by model and order when quoting |
|---|---|
| Preparation time | Availability and lead time are confirmed by model and order when quoting |
| Packing | Confirm pack quantity, protection and labelling for the selected model. |
| Samples | Sample quantity, fees and shipping are confirmed for the selected model. |
| Payment | Agree payment terms and the payee in the quotation and invoice. |
| Shipping | Confirm the shipping method, cost and timing for your destination and order. |
| Customization | State ROM, colour, marking and packing needs; feasibility and cost require confirmation. |
Key features
- “Touch and hold” format — a steel magnet ring seats the key on the contact and keeps it there for a first-touch read.
- DS1990A-compatible key pre-assembled into the fob as one complete unit.
- Housing colour, logo printing and fob shape can be requested. Colour, marking and other customization options: feasibility, MOQ and cost are confirmed in the quote.
Specifications
| Chip / compatibility | DS1990A format · model TMK-TM1990-R (iron-ring card) |
|---|---|
| Package | F5 key + iron retention ring + plastic fob — mates with magnetic readers |
| Mounting | Key ring / lanyard |
| Options | Colour, marking and other customization options: feasibility, MOQ and cost are confirmed in the quote. |
Inside the stainless can
Typical construction of this can format: a stainless-steel shell, an insulating grommet separating lid from base, and the chip bonded inside. Lid = data contact, base = ground return. Wall thickness, grommet material and other construction details: confirm for the supplied version.
Typical applications
Frequently asked questions
What does the magnetic ring on this key actually do?
The iron retention ring is designed to seat the key on a magnetic reader contact and hold it there, so that reading needs less pressing or aligning. That can matter on outdoor intercom panels and for users who struggle to hold a key steady; actual behaviour depends on your reader, so test a sample.
Does it also work on ordinary, non-magnetic readers?
It is intended to. It is offered as a DS1990A-class key — the magnet is meant only to add mechanical retention on magnetic readers, and on a plain probe it should read like a standard Touch Memory key. Compatibility depends on your reader, controller and firmware; test a sample on your own system before ordering.
Is it supplied assembled, and can the fob be customised?
Offered pre-assembled — key, iron ring and fob (model TMK-TM1990-R) — ready to distribute; confirm the supplied form in the quote. Colour, marking and other customization options: feasibility, MOQ and cost are confirmed in the quote.
